1. First of all, workers will turn off the power in the car and observe whether the car key is off. Use tools to remove the car seat to be installed with the heating system, and place it in a clean and spacious place...
2. Remove the seat and back cover (cloth or leather) of the car seat carefully, the worker will remember the order of removal. Determine the position of the car seat heating pad, the heating pad with the mesh adhesive...
3. Remove the mesh adhesive slowly from one end and paste it as you remove it. Sponge tires have stretching position, the heating pad into the bottom of the stretching groove, and the bottom of the groove close to keep flush.
4. Wear-resistant sticker is pasted in the stretching groove. Heating pad to keep flat, not wrinkled, car seat heating pad harness from the end of the sponge tire lead and the main harness docking. At this time the heating pad is paved, the workers will re-wrap the masking surface.
5. Install the heating switch in the customer's preferred position, and stick the opening sticker on the selected position. Drill with a drill in the opening sticker along the inner edge of the edge drilling, repair production edge, good workers do the switch will be very suitable, and the original car is very matching.
6, wiring. Long fire wire, key door, night line should be tested twice or more with an electric pen or multimeter to confirm that there is no error before connecting. Tower iron wire fixed on the tower iron screws, tower iron screws must not have paint rust.
7, under the car carpet for the arrangement of car seat heating pad main wiring harness.
8, it should be noted that: the harness fuse, relay and plug position is installed in the place of easy heat dissipation, pay attention to the wind away from the heater fan main harness should be avoided throttle linkage and the motorist easy to access position, to ensure driving safety and harness safety.
9, the switch will be installed to the pre-opened switch hole position, the entire system installation is complete.
10, car seat heating pad installation test: open the key door to the car start and turn on the night light, the car seat heating system switch to the highest gear, 5 minutes after the detection of the seat, leaning heating is normal. And check whether the heating indicator light and night light are normal.
